Description
………….
Mobile Hydraulic Scissor Lift Platform:
The movable hydraulic scissor lift is widely used for the equipments installations and maintenance,mainly used on construction sites, workshops, warehouse, airport, bus&railway stations, hotels,
garage, gas station, aerial pipeline, and so on.
………….
Features:
Platform height: 4m-18m.
Anti-slip checkered steel plate of the paltform surface.
Loading capacity: 300-8000kg.
Control method: electric or manual.
Lifting drive option: power wire supply, battery, diesel.
Motor: 380v, 220v, 50hz/60hz, can supply according to client’s need.
Emergency and overload protection devices.
Supply for operation and maintainance manual, hydraulic diagram, electric diagram,
good warranty and service.
…..
|
Model |
SJY0.3-8 |
|
Capacity |
300kg-500kg |
|
Table size |
2100*900mm |
|
Max platform height |
8m |
|
Working height |
9.7m |
|
Dimension |
2200*1060*1380mm |
|
Weight |
1050kg |
|
Motor |
1.5kw/380v/50Hz |
|
Cylinder |
HSG80/45 *2pcs |
|
Tire |
500-8,pneumatic |
|
Lifting speed |
4-6m/min |
|
Steel material |
Q235 carbon high strength steel. |
|
Platform thickness |
3mm steel plate bend, add 3mm diamond plate. |
|
Scissor rod |
Rectangular tube, size:120*60*4mm. |
|
Bottom frame |
Rectangular tube, size:100*50*4mm. |
|
Oil tube |
2-10-43MPa,Double steel net high-pressure tube. Inside explosion-proof valve. |
|
Pump station |
Anshenglisheng brand, with emergency oil returning valve. Inside has overflow valve, overload protection. |
|
Support legs |
4 pcs, Rectangular tube, size:100*50*4mm. |
|
Control box |
Delixi brands, contactor list links, equipped with thermal overload protection, phase losing protection. |
|
Control method |
Bottom and upper controls,Up.,down, stop and jerk button. |
|
Shaft pin |
45# round steel made, thermal refining. |
|
Bearing |
SF-2 oil-free self-lubricating bearings. |
|
Hydraulic oil |
32# Great wall brand. |
|
Derusting processing |
Shot and blasting derusting treatment,make the surface clean and effect of uneven, increase the adhesion of powder when paint. |
|
Paint |
Using electrostatic powder coating,strong adhesion,High brightness of color. Bake treatment. |
….
